Products may differ in size, colour and appearance to those shown. If you require further information or customisation, please contact us directly.
| Material | Polypropylene |
| Material sealing gasket | TPE |
| Temp. range min | -30 °C |
| Temp. range max | 100 °C |
| Temperatures during install. | -5 °C - 60 °C |
| Protection class | IP66 / IP67 |
| Glow wire test | 750 °C |
| Voltage | 690 V |
| Rated cross section | 10 mm² |
| Fixing | 4 internal openings |
| Ø cable diameter min | 6 mm |
| Ø cable diameter max | 21 mm |
| External dimensions LxWxH | 140 x 140 x 72mm |
| Using for cable gland |
 |
| Product Color | RAL 7035 |
| Order no. RAL 7035 | 10060704 |
| Type | COMBI IND 1010 LG |
| Packing unit | 2 |
| ETIM-Classification | EC002600 |
| EAN number | 4007685607049 |
| Tariff number | 39269097 |
| Remarks: IP66: using the QUIXX self sealing membrane screw IP67: using the knockout entry together with ESKV cable gland Equipment: - 10 knockouts side 5x M25/M32; 2x M20; 3x M20/M25 - 4 knockouts in the bottom 2x M25/M32; 2x M20/M25 - 4 captive cover screws - including QUIXX EMS self-sealing membrane screw 2x M25; 1x M32 Mounting: 4 internal openings outside of the sealing area |
|
Installation instruction 1010
