Products may differ in size, colour and appearance to those shown. If you require further information or customisation, please contact us directly.
| Material cable gland | polyamide UL94-V0 |
| Material sealing gasket | EPDM |
| Hazard level EN acc. 45545 | R22=HL3 / R23=HL3 / R24=HL3 |
| Protection class | IP68 (5 bar 30 min), IP69 |
| Thread type | M |
| Ø Connection thread D | 25 |
| Lead | 1,5 |
| Length screw-in thread L | 10 mm |
| Temp. range min | -40 °C |
| Temp. range max | 100 °C |
| Glow wire test | 960 °C |
| Ø cable diameter min | 9 mm |
| Ø cable diameter max | 17 mm |
| Key width SW | 29 mm |
| Collar diameter (E) | 32 mm |
| Total length TL | 38 mm - 47 mm |
| Type of cable anchorage | A |
| Install. torques fitting | 10 N m |
| Install. torques fitting/EADR | 4 N m |
| Install. torques cap nut | 4 N m |
| Impact category | 4 |
| Product Color | RAL 7035 |
| Order no. RAL 7035 | 10105495 |
| Type | ESKV 25 RW LG |
| Packing unit | 50 |
| EAN number | 4007686009828 |
| Tariff number | 39269097 |
| ETIM-Classification | EC000441 |
EU-Declaration of Conformity ESKV_DE
