Products may differ in size, colour and appearance to those shown. If you require further information or customisation, please contact us directly.
| Material cable gland | Stainless steel A2 (1.4305) |
| Material sealing gasket | Silicone |
| Material clamping cage | Polyamide UL94-V0 |
| Hazard level EN acc. 45545 | R22=HL3 / R23=HL3 / R24=HL3 |
| Protection class | IP69, IP68 (5 bar 30 min) |
| Thread type | M |
| Ø Connection thread D | 32 |
| Lead | 1,5 |
| Length screw-in thread L | 8 mm |
| Temp. range min | -60 °C |
| Temp. range max | 100 °C |
| Ø cable diameter min | 13 mm |
| Ø cable diameter max | 21 mm |
| Key width SW | 36 mm |
| Collar diameter (E) | 40 mm |
| Total length TL | 36 mm - 44 mm |
| Install. torques fitting | 20 N m |
| Install. torques cap nut | 20 N m |
| Impact category | 6 |
| WISKA-Order no. | 10105844 |
| Type | ESSKV 32 LT RW |
| Packing unit | 5 |
| EAN number | 4007686013047 |
| Tariff number | 73269098 |
| ETIM-Classification | EC000441 |
DNV-EMSKV-MMSKV-ESSKV_C-EN
